TBarCode SAPwin

TBarCode/SAPwin - Barcode DLL for SAP

TEC-IT's Barcode DLL for SAP is a software extension for SAPSprint, SAPlpd and SAPGUI (SAPWIN DLL). With the help of this Barcode DLL you print bar codes on all printers without additional hardware.

New in TBarCode/SAPwin 10.1: Unicode support for 2D Codes, 32 Bit and 64 Bit version, GS1 DataBar fixes!

Bar Code Printing in SAP

You want to print bar codes with SAP® ERP, SAP R/3® or mySAP® ERP?

·         Almost every printer in your company should be able to print barcodes? Of course also printers without special bar code support?

·         You already have a Windows print server in operation (SAPSprint or SAPlpd) or you want to print barcode documents directly on clients (SAPGUI)?

·         You need to print linear bar codes (like Code-39, Code-128, EAN-Codes...) and two-dimensional barcode symbologies like PDF417, Data Matrix or QR-Code?

·         A hardware independent solution is in demand, working with almost every printer and without requiring printer extensions (like Barcode DIMM or Barcode SIMM modules)?

·         And you expect skilled technical support?

Barcodes Quick and Simple...

1.       Download TBarCode/SAPwin - Barcode DLL for SAP.

2.       Install this SAP Barcode DLL on a Windows SAP client or on a print server (as extension for the spool transfer programs SAPSprint or SAPlpd).

3.       Add a printer with the device type SWIN (in transaction SPAD) and print through the server (or client) where you have installed TBarCode/SAPwin.

4.       Here you go - you already print bar codes.

Main Features of the Barcode DLL

TBarCode/SAPwin extends as Barcode DLL the SAP spool transfer programs SAPSprint and SAPlpd with bar code printing. In addition TBarCode/SAPwin can be operated with the SAPGUI Client for Windows.

The main advantages are....

·         All common linear and two dimensional bar codes used in industry and trade available in one product.

·         Bar code printing takes place printer independent and without hardware extensions. Exchanging printers is possible at any time. Broad range of supported printer models (activation through SAP spool transfer programs with Windows printer drivers).

·         Both operation on print servers and Windows clients possible (network and local printers).

·         Simple and hassle-free installation.

·         Straightforward usage in all documents (SAPscript, SmartForms, ABAP) with System Barcodes and Printcontrols

·         Generation of the bar codes in the highest possible output quality. Adaptation to toner saturation or ink spread is supported.

·         No data limit for 2D codes: You can print several thousand Bytes per symbol.

·         Very cost effective…
Per printer costs: none. Costs when exchanging printers: none. Costs for hardware upgrades: none. Printer font downloads: none. SAP form modifications: none. Installation efforts (system level): nearly zero. Product support: free!

Function Principle

SAPSprint, SAPGUI or SAPlpd receive the print jobs in SAPWIN data format and translate them into the final printer language by utilizing the Windows printer driver. During this process the bar code print controls from the device type are passed over to the Barcode DLL for bar code creation. The print controls are converted to a high resolution bar code image (EMF vector format), which is embedded into the print job.

All supported bar code formats are configurable through one single interface. All printers can be used through the delivered Windows printer driver.

The bar codes are generated exclusively by our software namely in the highest possible resolution and output quality. That way you can equip all your printers hardware independent and enterprise wide with bar code capabilities.

Supported Operating Systems & SAP Components

·         Bar code extension for SAPsprint, SAPlpd and SAPGUI (SAPWIN.dll)

·         For SAPlpd Version 3 or higher

·         For SAPSprint V1.0.0.1 or higher (32 Bit and 64 Bit Version)

·         For SAPGUI with SAPwin.dll V1.0.0.6 or higher (32 Bit and 64 Bit Version)

·         For EH&S WWI SP31 or later

·         For Microsoft® Windows XP SP3, 2003, Vista, 7, Server 2008 (32 + 64 Bit), 2008R2, 8, 2012, 2012R2, 10

·         For SAP R/3 Release 2.2 and all newer SAP ERP systems

·         With SPAD Host Spool Access F, S, U or G in combination with all SAPWIN/SWIN based device types

·         Barcode management through System-Barcodes, Printer Barcodes and Printcontrols.

·         Suitable for SAPscript, SmartForms and ABAP

Supported Barcode Symbologies

Linear Bar Codes (1D Barcodes)

CodaBar 2 Widths

CodaBar (2 Width), CodaBar2

Code 2OF5 IATA

Code 2 of 5 IATA Version (International Air Transport Association)

Code 2OF5 Industry

Code 2 of 5 Industry Version

Code 2OF5 Interleaved

Code 2 of 5 Interleaved (alias ITF or Code 2/5 IL),

Code 2OF5 Matrix

Code 2 of 5 Matrix (alias 2of5 Standard)

Code 2OF5 Standard

Code 2 of 5 (identical with Code 2 of 5 Matrix)

Code 32

Code 32 (Italian Pharmacode)

Code 39

Code 3 of 9 alias Code-39

Code 39 Full ASCII

Code 3 of 9 Extended Version (ASCII)

Code 93

Code 93

Code 93 Full ASCII

Code 93 Extended Version (ASCII)

Code128

Code-128 all sub sets and Compressed Mode

Code128A

Code 128 Subset A

Code128B

Code 128 Subset B

Code128C

Code 128 Subset C

EAN8

EAN-8 (also JAN or IAN)

EAN8P2

EAN-8 (also JAN or IAN) with 2 digit add-on

EAN8P5

EAN-8 (also JAN or IAN) with 5 digit add-on

EAN13

EAN-13 (also JAN or IAN),

EAN13 P2

EAN-13 (also JAN or IAN) with 2 digit add-on

EAN13 P5

EAN-13 (also JAN or IAN) with 5 digit add-on

EAN14

EAN-14 (GTIN coded with GS1/EAN-128 symbology)

EAN128

EAN-128 alias UCC-128 alias GS1-128

Flattermarken

Flattermarken

GS1-128

GS1-128, identical to EAN-128 / UCC-128

GS1-DataBar

GS1-DataBar Symbologies (all based upon RSS Codes)

ISBN-13

ISBN-13 (International Standard Book Number, 13 digits)

ISBN13-P5

ISBN13 with 5 digit supplement

ISMN

ISMN (International Standard Music Number)

ISSN

ISSN (International Standard Serial Number)

ISSN P2

ISSN with 2 digit supplement

ITF-14

ITF14, Code 2of 5 Interleaved (14 digits)

LOGMARS

DOD Logmars, Department of Defense Logmars

MSI

MSI Barcode variants with different check digits

Pharmacode One-Track

Pharmacode One Track (1 Track)

Pharmacode Two-Track

Pharmacode Two Track (2 Track)

PLANET 12 Digit

Planet Code 12 digits (Postal Alpha Numeric Encoding Technique)

PLANET 14 Digit

Planet Code 14 digits

Plessey

Plessey Unidirectional

Plessey Bidirectional

Plessey Bidirectional

PZN7

Pharmazentralnummer Germany (PZN/PZN7)

PZN8

Pharmazentralnummer Germany (PZN8)

RSS Expanded

EAN/UCC RSS Expanded (Reduced Space Symbology)

RSS Limited

EAN/UCC RSS Limited (Reduced Space Symbology)

RSS-14

EAN/UCC RSS14 (Reduced Space Symbology)

RSS-14 Truncated

EAN/UCC RSS14 Truncated (Reduced Space Symbology)

RSS-14 Limited

EAN UCC RSS14 Limited (Reduced Space Symbology)

SSCC-18

SSCC 18 Shipping Container Code

Telepen

Telepen

Telepen Alpha

Telepen Alphanumeric

UCC/EAN-128

UCC/EAN 128

UCC-128

UCC 128

UPC12 / UPCA

UPC 12 (alias UPC-A),

UPC-A

UPC A (alias UPC-12),

UPC-A P2

UPC Version A + 2 digit supplement

UPC-A P5

UPC Version A + 5 digit supplement

UPC-E

UPC Version E

UPC-E P2

UPC Version E + 2 digit supplement

UPC-E P5

UPC Version E + 5 digit supplement

UPCSCC

UPC Shipping Container Code (refer to ITF14, SCC-14)

VIN / FIN

Vehicle Identification Number, Fahrzeug-Identifizierungsnummer

Postal Codes (1D Postal Barcodes)

Australian Post Custom

Australian Post Standard Customer, Customer2, Customer 3

Australian Post Redirect

Australian Post Redirection

Australian Post Reply Paid

Australian Post Reply Paid

Australian Post Routing

Australian Post Reply Routing

Brazilian CEPNet

Brasilianischer Post-Barcode

DAFT Code

DAFT is an artificial generic code

DPD Code

German Parcel Service Label Code

DP Identcode

Deutsche Post Identcode

DP Leitcode

Deutsche Post Leitcode

Italian Postal 2of5

Italian Postal Code (based on 2of5 IL)

Italian Postal 3of9

Italian Postal Code (based on Code 39)

Japan Postal

Japan Postal 4-State Bar Code

KIX

Dutch Postal Barcode

Korean Postal Authority

Korean Postal Barcode

RoyalMail 4State (RM4SCC)

Royal Mail 4 State Barcode (RM4SCC)

USPS OneCode (4-CB)

see USPS Intelligent Mail® Barcode

USPS Intelligent Mail® Barcode

USPS Intelligent Mail® Barcode, alias USPS OneCode alias USPS 4-State Customer Barcode

USPS PostNet5

USPS PostNet ZIP (5 digits) with check digit computation

USPS PostNet9

USPS PostNet ZIP+4 (9 digits) with check digit computation

USPS PostNet11

USPS PostNet ZIP+4+2 (11 digits) with check digit computation

Two Dimensional Barcodes (2D Barcodes)

Aztec Code

Aztec Code (available in TBarCode/SAPwin Version 8+)

Codablock-F

CodablockF (Stacked Code128), used by HIBC

Data Matrix

Data Matrix (ECC200 standard with error correction)

DP Postmatrix

Deutsche Post Werbeantwort Postmatrix

GS1 Data Matrix

Data Matrix with GS1 format (ECC200, FNC1), Auto Compaction

MaxiCode™

Maxi Code™ (used by UPS®)

Micro QR-Code

Micro QRCode (Micro Quick Response Code, available in TBarCode V9 & Barcode Studio V9)

MicroPDF417

Micro PDF-417, MicroPDF

PDF417

PDF-417 (used by VDA, GTL, ODETTE, VDA Belom...),

PDF417 Truncated

PDF-417 Truncated Version

QR-Code

Quick Response Code (ISO/IEC 18004:2000); uses 932/Shift-JIS standard character set

QR-Code 2005

QRCode 2005 (ISO/IEC 18004:2006); uses Latin-1 (ISO-5589-1) as standard character set

RSS-14 Stacked

EAN/UCC RSS14 Stacked

RSS-14 Stacked Omnidir

EAN/UCC RSS14 Stacked Omnidirectional

RSS Expanded Stacked

EAN/UCC RSS Expanded Stacked

HIBC Barcodes (available in TBarCode/SAPwin Version 9+)

HIBC LIC 128

HIBC LIC variant of Code 128

HIBC LIC 39

HIBC LIC variant of Code 39

HIBC LIC Codablock-F

HIBC LIC variant of Codablock-F

HIBC LIC Data Matrix

HIBC LIC variant of Data Matrix

HIBC LIC MicroPDF417

HIBC LIC variant of MicroPDF417

HIBC LIC PDF417

HIBC LIC variant of PDF417

HIBC LIC QR-Code

HIBC LIC variant of QR-Code

HIBC PAS 128

HIBC PAS variant of Code 128

HIBC PAS 39

HIBC PAS variant of Code 39

HIBC PAS Codablock-F

HIBC PAS variant of Codablock-F

HIBC PAS Data Matrix

HIBC PAS variant of Data Matrix

HIBC PAS MicroPDF417

HIBC PAS variant of MicroPDF417

HIBC PAS PDF417

HIBC PAS variant of PDF417

HIBC PAS QR-Code

HIBC PAS variant of QR-Code

EAN-UCC Composite Variants



RSS-14

Composite Component CC-A / CC-B

RSS-14 Stacked

Composite Component CC-A / CC-B

RSS-14 Stacked Omnidirectional

Composite Component CC-A / CC-B

RSS Limited

Composite Component CC-A / CC-B

RSS Expanded

Composite Component CC-A / CC-B

RSS Expanded Stacked

Composite Component CC-A / CC-B

EAN 13

Composite Component CC-A / CC-B

EAN 8

Composite Component CC-A / CC-B

UPC A

Composite Component CC-A / CC-B

UPC E

Composite Component CC-A / CC-B

UCC/EAN128

Composite Component CC-A / CC-B / CC-C

GS1 DataBar Composite Variants (2D Barcodes)

GS1 DataBar

Composite Component CC-A / CC-B

GS1 DataBar Stacked

Composite Component CC-A / CC-B

GS1 DataBar Stacked Omni

Composite Component CC-A / CC-B

GS1 DataBar Limited

Composite Component CC-A / CC-B

GS1 DataBar Expanded

Composite Component CC-A / CC-B

GS1 DataBar Expanded Stacked

Composite Component CC-A / CC-B

SAPscript Print Controls (Short Extract)

Barcode types

Print Control parameter "C" specifies the bar code type.

Width

Specification in mm / Print Control parameter "B"

Height

Specification in mm / Print Control parameter "H"

Check-Digit

yes/no - depending on bar code / Print Control parameter "P"

Human readable text

yes/no / Print Control parameter "A"

Position x, y

Specification in mm or actual cursor position / Print Control parameters "X" and "Y"

Bar Width Ratio

User specified ratio or standard ratio (depending on bar code type) / Print Control parameters "S1".."S4"

Space Width Ratio

User specified ratio or standard ratio (depending on bar code type) / Print Control parameters "L1".."L4"

Advanced Barcode Settings

·         Pixel shaving to minimize print tolerance on common printing methods.

·         Global shift parameter for vertical adjustment of barcode position (avoids changes in form, compensates printer driver differences).

·         Common industry default values can be activated (compliant to barcode DIMM/SIMM modules).

·         Global font style settings for Human Readable Text in EAN/UPS codes (changes in device type or form are non-requisite).

·         Orientation (0°, 90°, 180°, 270°)

·         Check digit calculation method

·         Module width, bar width ratio

·         Code subset for bar code variants

·         Binary encoding and encoding of non-printable characters

·         Escape sequences ("Test\13" == "Test" + Carriage Return)

·         Extended parameters for 2D bar code symbologies (line height, error correction level, columns,...)

·         Extensive data logging capabilities for trouble shooting.
