Addflow for WPF 2016 is a WPF Custom control created with the Microsoft .NET Framework 4.0 and VS 2013. It provides a small deployment assembly (250 Kb), a light programming interface, speed (We use virtualization and low-level DrawingVisual objects to obtain the most lightweight way to perform drawing), full integration with the WPF environment. You may order either a standard edition, either a professional edition of AddFlow. The professional edition provides a set of graph layout algorithms.

License agreement

Source code license agreement

Tutorial

Order

AddFlow for HTML5 v1.2.1.0

Addflow for HTML5 is a 100% Javascript Flowcharting/Diagramming component using the HTML5 Canvas. It lets you quickly build flowchart enabled HTML5 applications like workflow diagrams, database diagrams, communication networks, organizational charts, process flow, state transitions diagrams, telephone call centers, CRM (Customer Relationship Management), expert systems, graph theory, quality control diagrams, etc. Very easy to use, very LIGHT, very customizable. The professional edition provides a set of graph layout algorithms. Royalty free redistribution.

Evaluation license

Commercial license

Tutorial

Order

AddFlow for Silverlight v2.0

Addflow for Silverlight is a Silverlight Custom control created with Silverlight 5 and VS 2012. It offers the following advantages:

A small deployment assembly. The size of the Lassalle.Silverlight.Flow.dll file is just 225 Kb!!

A light programming interface: we do not provide an inflation of classes and properties.

Separation between visual appearance (defined in xaml) and logic. Every visual elements can be customized.

Full integration with the Silverlight environment

You may order either a standard edition, either a professional edition of AddFlow. The professional edition provides a set of graph layout algorithms.

The version 2.0 offers some new features like virtualization, zoom box (bird view), grid, IsFixedSize property, context handles.

AddFlow for Winforms 2015

AddFlow for WinForms 2015 is a .NET Windows Forms Custom control. It is 100% Managed Code.

AddFlow for WinForms 2015 is NOT compatible with previous versions.

What has changed ? Almost everything.

Why ? Those changes were necessary to allow a better evolution of the product for the future, to provide a lighter product that just does its job and nothing more, to take account of some new technologies like LINQ and for a better compatibility with other versions, especially the HTML5 version of AddFlow.

Does it provide the same features as previous versions ? Some minor features have been removed.

Does it provide new features ? Yes (pins, captions,orthogonal links, quadtree...)

It offers the following advantages:

A small deployment assembly. The size of the assembly file is just 250 Kb

A light programming interface: we do not provide an inflation of classes and properties.

A light programming interface, great flexibility and full integration with the Winforms environment.

Every visual elements can be customized: nodes, links, captions, resizing handles, etc...

Runtime Royalty free.

You may order either a standard edition, either a professional edition of AddFlow. The professional edition provides a set of graph layout algorithms.

AddFlow ActiveX v5.4

AddFlow is an ActiveX control that lets you quickly build flowchart-enabled applications. Features such as distinct colors, fonts, shapes, styles, pictures, text, and so on for each object of the diagram (node or link) are available. Nodes stay connected when moved. Metafiles support, serialization, multi-level undo/redo, printing, zooming, Bezier and spline curves, reflexive links, link jumps, gradient colors, link autorouting, custome shapes, multiselection, scrolling, user data association, navigation in the graph. You may order either a standard edition, either a suite edition of AddFlow. The suite edition provides a set of graph layout algorithms (Hierarchic, Force-directed, orthogonal, tree, radial, series/parallel).
