Construct for SpaceClaim
Focus on the design, automate the rest.
Construct for SpaceClaim is a tool that simplifies designing constructions. The tool is developed with the idea to simplify and automate designing constructions. For example, think of designing frames based on a selection of lines, or adding standard fasteners or base/cap plates with a single click.
Frame Generator
- Create a frame from a wireframe using standard profiles.
- Add or adjust joints
- Create a Bill of Material
- Export all components as a separate file
Plates
Addition of standard:
- Base plate
- Cap plate
- Support
- Flange
Fasteners
- Simple addition of standard fasteners
- Identical holes without a fastener are recognized automatically
- Add/adjust parameters of the fasteners manually
Connector
- Create connectors with a single click
- Works for many shapes such as sheet metal and tubes/pipes
- Define the connector shape based on parameters
Extra capabilities:
In addition to the tools presented above, there are some more functions that speed up the design process:
- Engraving: Add an engraving or note with a single click on (multiple) faces
- Rib CutOut: Connect ribs due to cutouts
- Custom Property: Add custom document or component properties based on a customizable template.
- Profile: Quickly create beams/tubes/pipes according to defined profiles and parameters.
