TMS FNC Chart

TMS FNC Chart

Fully cross-platform chart component designed for business, statistical, financial & scientific data



TMS FNC Controls can be simultaneously used on these frameworks:



TMS FNC Controls can be simultaneously used on these operating systems:



TMS FNC Controls can be simultaneously used on these IDE's:



Features



Highly configurable cross-platform chart.

Support for VCL Win32/Win64, FMX Win32/Win64, macOS, iOS, Android, LCL Win32/Win64, macOS, iOS, Android, numerous Linux variants including Raspbian

Support for multiple series with optional separate or combined auto range for x- and y-axis.

Wide range of chart types: bar, grouped bar, absolute stacked bar, percentage stacked bar, area, stacked area, pie, donut, spider, line, digital line, OHLC, CandleStick, Boxplot,...

XY line and XY scatter chart types.

Legend with glyph representing the chart type for each series.

Formatting of values in various formatting types (numbers, floating point numbers and date time)

X-axis and y-axis with optional custom formatting for each series and multiple position support.

Optional configurable background grid.

Series markers with bitmap and custom drawing support.

Series labels with formatting support and optional stacked mode.

Annotations for each series point.

Optional 3D drawing mode.

Design time editor.

Separate runtime editor for desktop operating systems.

High number of events for further customization.

Anti-aliasing & native canvas support.

Opacity support (FMX only)



Supported frameworks and platforms

VCL Win32/Win64

FMX Win32/Win64, macOS, iOS, Android

LCL Win32/Win64, macOS, iOS, Android, numerous Linux variants including Raspbian



Supported IDE's

Delphi XE7 and C++ Builder XE7 or newer releases

Lazarus 1.4.4 with FPC 2.6.4 or newer releases.
