IDAutomation Code 128 Barcode Font

 Code 128 Barcode Font Package

•Generate Code-128 and GS1-128 barcode symbols from a font.

•Contains over 18 different Code 128 font versions in 7 sizes.

•Examples for Microsoft® Excel, Access, FileMaker and Crystal Reports included.

•TrueType, OpenType, PCL LaserJet soft fonts and PostScript font versions are included.

•Supports GS1-128, AIM USS Code-128, ISS-Code-128, UCC-128, EAN-128, SCC18, USPS, SISAC,  IMpb,  IPA,  ISAL, Canada Post and other specifications based on Code-128.

•Compatible with Windows, Android and other various operating systems.*

•All Code 128 Fonts require special formatting so that the data, when the barcode font is applied, will be scannable. Over 30  royalty free font encoders, macros and plug-ins are provided to complete this automatically, including a stand-alone Font Encoder Software Application.

•With a purchase of the Developer License or above:  Web Fonts are included in WOFF, EOT and SVG formats to easily display barcodes in any web browser.

  A silent installation executable is included with source to create custom installations.

  Additional font encoders are provided including C++, Java, Oracle and .NET.

* For Mac, Linux, UNIX and iOS users, it is suggested to use the Code 128 for Mac Fonts or Universal Fonts, which provide additional Mac specific font encoders for easier integration.

This Code 128 font package includes over 18 Code 128 barcode fonts in 6 formats, with royalty free rights to use any IDAutomation font encoders, macros and source code as necessary for application integration. The fonts comply with all ANSI, AIM, ISO and European (CEN) standards for Code 128 including GS1-128 and ISS-128.

* For Mac, Linux, UNIX and iOS users, it is suggested to use the Code 128 for Mac Fonts or Universal Fonts, which provide additional Mac specific font encoders for easier integration.

Details of the Code 128 Barcode Font  Package

Encoding Tools Provided:

Over 30 Font Encoders are available for easy Code 128 font integration into a variety of applications including:

•User Tools:

   Font Encoder Software Application

   Microsoft Word & Excel Barcode Add-In

   Excel, Access & Word VBA Macros & Functions

   Crystal Reports Font Formulas

   FileMaker Pro Custom Functions

  Microsoft Office Macros & VBA

•Developer Tools:

 .NET Assembly DLL

  C++ Header File

  C# Barcode Library

  Java Class Library Barcode Font Encoder

  Oracle Reports Barcode PL/SQL Library

 Complete Index of Font Encoders

Industry Standard Support:

In use since 1998, IDAutomation Code 128 barcode fonts were created directly from AIM and ISO standards. The fonts comply with all ANSI, AIM, ISO and European (CEN) standards for Code 128 including GS1-128 and ISS-128.

•Code 128 Barcode Font Advantage PackageGS1-128 Support:    The Code128() function in IDAutomation font encoder tools provides an automated method to generate GS1-128. Additionally, the IDAutomationC128M font is specifically designed for GS1 barcodes when printed at 12 points where a size of 1/2 inch tall and an X dimension of 10 mils is required.

•USPS GS1-128 and IMb Support:

IDAutomationC128L will produce the exact dimensions for GS1-128 as required by the USPS special services when printed at 16 points, which is a height of .75" and an X dimension of .013".

  IDAutomationC128S at 28 points will produce a barcode at 23.5 mils and .81" tall, which meets requirements for the USPS Intelligent Mail (IMb) Container Barcode USPS-B-3215.

•Canada Post Support:

  When printed at 21 points, the IDAutomationC128L font will produce the dimensions required by the CANADA POST, which is a height of 1" and an X dimension of .017".

Multiple Language and Locale Support:

In the event the system regional setting is not set to "English" or the 1252 Latin-1 codepage, Code 128 fonts support the following additional code pages in Windows: 1250 European, 1251 Cyrillic, 1253 Greek, 1254 Turkish, 1255 Hebrew and 1256 Arabic.

Multiple Versions Provided:

•7 Font Heights Provided:

  In addition to using the point size to set the font width, seven (7) versions of the Code 128 barcode fonts are provided to support different height requirements.

•Standard and Symbol Encoded Fonts:

   Symbol Encoded Fonts on Windows allow the font name to appear in font selection dialogs.

•Human-Readable Versions:

  Separate fonts with text interpretations are provided for Code 128 sets B and C.

•Low-Resolution Printer Support:

  These Code 128 barcode fonts are designed to print precisely on 203 DPI thermal printers and 300 DPI printers in addition to higher resolution printers.

  When printing at 203 DPI, the point size chosen should be a multiple of 6.

  When printing at 300 DPI, the point size chosen should be a multiple of 4.

Multiple Formats Provided:

The following versions are provided with purchase:

TrueType Fonts:   TTF fonts are supplied as digitally signed, OpenType fonts with TrueType outlines. They are compatible with Mac OS X and all versions of Microsoft Windows®, including XP, Windows 7, Windows 10, Server 2012 and mobile devices including iOS, Android and .NET Compact Framework.

  TrueType fonts with symbol encoding are also provided which allow the font name to be more visible in font drop down lists of end-user Windows applications.

  Mac classic TrueType (MTT) fonts are included for Mac System 7.1 to OS X.*

•OpenType Fonts:   The OTF fonts are digitally signed, OpenType fonts with PostScript outlines compatible with Windows, Mac OS X, Linux and other systems supporting the OpenType format.

•PostScript Fonts:   PostScript Type 1 fonts are supplied in binary (PFB), ASCII Type 1 (PFA compressed and uncompressed) and Mac classic versions (MT1 and BMA).

•PCL Fonts:   PCL LaserJet soft fonts are provided in 8, 12, 16, 20 and 24 point bitmap sizes. Other sizes may be provided  by request for all developer license purchases.

Included with the purchase of any Developer License:

•With a purchase of the Developer License or above, Web Fonts are included in WOFF, EOT and SVG formats to easily display barcodes in any web browser.

•A silent installation executable is included with source scripts to create custom installations.

•The Developer License grants the right to convert IDAutomation's fonts to other formats as necessary.   Barcode fonts included with the Developer License allow embedding into PDFs, Word documents and other files that support embedding so those who do not have the fonts installed may still view and print the barcode.

•  Custom modifications of the fonts may be requested, including changes to the font name, size, height and copyright notice.

* Note to Mac users, while the Code 128 package is compatible with Mac OS X, it is recommended to use the Code 128 for Mac, which includes free font encoders designed for the Mac to create Code 128 barcodes easily and ensure complete compatibility with all countries and locales on any device.

Code 128 Mac Barcode Font by IDAutomation

•Generate code 128 barcodes for Mac from a font.

•Cross-platform compatible with all operating systems.

•Works with any font codepage in any country.

•The package includes examples for Microsoft® Excel and FileMaker.

•OpenType, TrueType, PostScript and PCL font versions included.

•Web Fonts are also included with a purchase of any Developer License.

Proprietary formatting within IDAutomation's Universal Font for Mac provides complete compatibility with all countries and locales on any device. This implementation is unique because other Code 128 fonts use extended  ASCII characters (over ASCII value 126) that differ on the Mac.

A correct Code 128 symbol is created by combining the data that is returned from a  universal font encoder with the IDAutomation's Universal Barcode Font. Several encoders are provided that are Mac compatible including 4D, Excel, OpenOffice, Java, AppleScript, a FileMaker Pro plugin and C++ header .h files that are compatible with Xcode.
